EDPRO36BT-E7 | EDGE DB Series 3.7 inch 160 watts Pro Audio Tweeters - Pair
The first introduction into Pro audio tweeters is in the DB series where we feature 2 Bullet tweeters, high frequencies at high volume.
The DB series Pro speakers are Ferrite magnet based drivers with Aluminium diaphragms for high volume, high frequency sound. The Horn designs allow a wide sound dispersion and a high level of efficiency meaning the speaker will be loud even at its minimum power input.
Its cast Aluminium housing ensures a robust solid functional design with no added resonance to distort the sound and a high quality feel.
Our DB series bullet tweeters have been engineered to match our range of Pro audio speakers, so when paired together you get a full range, high volume Pro audio sound.
Features
- Aluminium diaphragm
- Cast Aluminium flange
- Spade terminal
- High sensitivity
Specification
- Type: Pro Audio Tweeter
- Configuration: 1 way
- Speaker Size: 3.7" (95mm)
- RMS Power: 80 watts
- Peak Power: 160 watts
- Frequency Response: 2kHz - 20kHz
- Sensitivity: 105dB
- Impedance: 4 Ohms
- Recommended Amplifier: EDB80.4LITE-E0
Installation
- Mounting Depth: 1.5" (39mm)
- Mounting Diameter: 4.6" (117mm)
Downloads
